This chapter introduces the main concepts of Attack Flow with visual examples taken from the Attack Flow Builder. The example start with simple scenarios and work up to complex situations.

Action Objects

An action represents an adversary executing a specific technique. For example, T1566: Phishing is a common adversarial technique that captured in the ATT&CK knowledge base. If an adversary utilizes this behavior during a specific breach, then that is an action.


The examples here depict ATT&CK techniques, but Attack Flow does not require the use of ATT&CK. You may use custom collections of techniques, e.g. created in Workbench, other knowledge bases such as VERIS, or even create ad hoc actions to describe techniques that are not part of any pre-existing taxonomy.

Adversary behavior is the focal point of the Attack Flow project, and actions are the backbone of any flow. Sequences of adversary behavior are represented by connecting actions together with an arrow.

A spearphishing action connected to a user execution action.

An action connected to another action represents a dependency between them.

When two actions are connected together, it represents a dependency between them: the second action cannot be executed until the first action completes successfully. (The handling of failed actions is discussed later.) This is not equivalent to saying that one action happened before another! This is a more powerful concept that models how an adversary uses one behavior to create the preconditions they need to execute the next behavior.

Condition Objects

Sometimes the relationship between two actions is not immediately obvious to the reader, especially if the underlying techniques are especially obscure or rare. A condition describes the state of the world after the preceding action finishes. This can be used to clarify for the reader how two actions are related, i.e. what one action accomplishes that enables the next action to run.

LSASS dumping action leads to password cracking option, which leads to a condition, which leads to a registry run keys action.

A condition clarifies how the outcome of an action sets up the execution of another next action.

In the example above, the reader may not know enough about LSASS, password hashes, or password cracking to understand how the first two actions lead to the third. The condition object fills this gap by succinctly describing the outcome (or effect) of the first two actions that enables the third action.

Parallel Attack Paths

The adversary may have multiple available techniques to execute in a given scenario. In the next example, the attacker has used two different persistence mechanisms. Although the attacker is not literally executing these techniques simultaneously, it helps to think of these as “parallel” attack paths because neither technique depends on successful execution of the other.

One action is connected to two other actions.

The attack branches out to show that the adversary has multiple persistence techniques.


Flows can represent adversary behavior in different scopes, e.g. portraying a single specific incident versus portraying an overall campaign. In a specific incident scope, parallel attack paths indicate the attacker executing different techniques. On the other hand, the campaign scope rolls up behavior across multiple incidents, so parallel paths represent the different behaviors that have been observed across multiple incidents.

Operator Objects

After a flow splits into parallel attack paths, operators combine them back together. An OR operator means that only of the incoming attack paths needs to succeed in order to continue the flow, while an AND operator means that all of the incoming attack paths must succeed in order to continue. The next example shows that the adversary has two different techniques for pivoting into a different user account. If either technique succeeds, then the attack can continue forward.

Two actions are connected to an OR operator, which is then connected to a third action.

An OR operator shows that the attacker has two different techniques for pivoting to a local user account.

When multiple attack paths are combined, the logic can be difficult for the reader to follow. This is a great place to use conditions to clarify what the state of the world is at that point in the flow.

Two actions are connected to an OR operator, which is then connected to a condition, which is then connected to a third action.

A condition object clarifies how the actions before the operator are related to the action after the operator.

Perhap the reader does not understand the consequences of dumping LSASS memory or how it relates to the actions that come afterward. The condition clarifies that the adversary is now able to pivot into a different user account.


It is possible to join paths together without using an operator by simplying pointing two arrows at a single action or condition. This approach is ambiguous because it’s not clear how the sucess or failure of those paths affects the outcome of the flow, but ambiguity may be appropriate in some circumstances, e.g. if the underlying CTI is itself ambiguous.

Asset Objects

Each action can potentially have some outcome or effect on the world. It is often informative to describe the effect in terms of some object in the world that has been impacted. Actions can point to assets to indicate which objects are impacted as well as which objects are used in subsequent techniques.

One action connects to another; both are connected to the same asset, which is in turn connected to a user account object.

An asset clarifies how actions modify the state of the world or depend on the state of the world.

In this example, the asset shows which particular password hash was disclosed by LSASS memory dumping. Later in the flow, the adversary cracks that password hash. An asset can also point to another object to provide additional structured data.


The user account object in this example is one of the many available STIX objects. This aspect of Attack Flow is covered in depth later in this chapter.

Success and Failure

When modeling complex adversary behavior, conditions can also depict how the attacker handles branches that are only feasible in specific circumstances.

An actions points at two conditions. Each condition points to a separate action.

Conditions model when different branches of the attack can be taken.

In this example (an excerpt from the NotPetya flow), the malware has two different privilege escalation techniques. Each technique depends on the host process having a specific Windows privilege. The conditions depict what state is required for each path to continue executing. The attack can go down one path, both paths, or neither path depending on the state of the host process.

Conditions can also model how the adversary handles failure. All the examples up to this point have used the true branch of each condition to represent what happens when the underlying condition is true. But conditions also have a false branch that is activated when the condition is not true.

An action points to a condition. The true and false branches of a condition point at separate actions.

The “false” branch portrays what happens when a technique fails.

In this example, the adversary attempts to steal a targeted user’s credentials via spearphishing. Since this technique relies evading email filtering and tricking users, it is inherently unreliable. The condition object after spearphishing shows a decision point for the adversary: if they obtained a credential then they can move on to logging in with it. But if the spearphshing fails, then the adversary falls back to a password spraying technique in another attempt to obtain a valid credential.

Additional STIX Objects

This introduction focuses on the core Attack Flow objects, but Attack Flow is based on the STIX industry standard, so you can also use any available STIX object in your flows! STIX contains a variety of useful objects to enrich your flow with including IOCs and contextual details. This next example shows the standard STIX process object being used to provide details about how the file discovery technique was executed.

An action points to a process object.

The process object provides technical details regarding how the action was executed.

Now that you are familiar with the central concepts, continue reading to review the corpus of example flows and how to use the Attack Flow Builder to start creating your own flows.
