Introduction
Project Goal
The Pyramid of Pain 1 has been used by detection engineers to determine the cost or “pain” it would cause an adversary to evade defenses that are effective at that level of the pyramid. Starting at the bottom: hash values, IP addresses, and domains are trivial for an adversary to change and continue their attack. Indicators further up the pyramid are more difficult for an adversary to change and consume more time and money. Tactics, Techniques, and Procedures (TTPs), such as those in MITRE ATT&CK®, are at the top of the pyramid because they are the most costly to change.
Pyramid of Pain by David Bianco
Detection engineers can leverage the Pyramid of Pain to understand how difficult it is for adversaries to evade their analytics. A detection analytic focused on identifying hash values will be precise in detecting a specific malware binary but will not detect a variant of that malware that has been altered by even a single byte. A detection at the tool level might be robust in detecting specific implementations of a technique but could create more false positives, pick benign user activity, and alert on system-generated noise if the implemented tool is native to the OS. Some analytics might use a combination of various indicators to increase both the Precision and Recall of an adversary attack. In this work, we introduce–and focus on improving–a new metric called Robustness.
Important
Adversaries can attack different parts of the OS and might be operating at a level that the deployed sensors cannot detect. Therefore, it is imperative that defenders understand where and what type of activity their analytics are detecting.
Deconstructing the Pyramid
Let’s break down the pyramid into the different types of activity a defender can build their analytics around.
The first four levels of the pyramid are focused on ephemeral values which are easy for an adversary to change. The next level is not focused on values, but the types of tools an adversary will attempt to use during an attack. Finally, the top level is strictly focused on behaviors which an adversary will demonstrate during an attack.
Deriving the five rows of the Summiting model.
Having consolidated the pyramid of pain into three new groupings, the next step is to break out the tools and behavior groupings to derive the five rows used in the Summiting model. Each row corresponds to a group of observables that we can use to build analytics. The bottom row represents ephemeral values, which are trivial for an adversary to change.
The next two rows distinguish two types of tools. Adversary-brought tools are brought in by an adversary to accomplish an attack. Pre-existing tools such as LOLbins) are available to defenders before adversary use, making it more difficult for an adversary to modify. These two levels were split in recognition of the fact that an adversary will have more control over tools they bring to an attack, making it easier for them to evade specific tool detections. Tools which are managed by the target organization, on the other hand, may not be as easy for the attacker to modify.
The behavior grouping is also split into two levels. These groupings are focused on identifying behaviors that are associated with MITRE ATT&CK Techniques, making them the most difficult to evade, and providing defenders the tools to create the most robust analytics. The observables core to some implementations of a technique are associated with low-variance behaviors which are unavoidable without a substantially different implementation. Observables core to a technique are the choke points or invariant behaviors, which are unavoidable by any implementation.
In addition to these five rows, the Summiting model also contains three columns that correspond to where detection signals come from. An OS will generate events, which can be used by a defender to detect malicious activity. These are usually seen in the form of event IDs. However, not all event IDs are generated in the same part of the OS. Some are generated by applications, some can be called by the user, some are functions of the kernel, and so on. Adversaries may be able to bypass certain event IDs by calling lower-level APIs in the OS or making direct syscalls into the kernel.
Understanding this concept can help defenders build more robust analytics, by looking at different sensor data throughout the OS. This second dimension in our model represents sensor data robustness.
The Summiting model contains five rows and three columns.
There are three different layers within the OS in which sensor data can be generated. The application column identifies observables which are associated with the use of libraries, such as DLLs, available to defenders before adversary use. These are difficult for the adversary to modify, but can be evaded. User-mode observables are associated with user-mode OS activity, such as Sysmon process creation. Finally, kernel-mode observables are associated with kernel-mode activity occurring at ring 0. Each of these columns provide the defender a different layer to detect activity within the OS, going deeper as the columns move to the right.
This model can be used to visualize the robustness of an analytic, based on its evadability and log source.
Improving Analytic Robustness
Let’s step through an example. The below analytic looks for specific command line
arguments of the ADFind tool 2, identified when the process image ends with
adfind.exe.
title: Suspicious AdFind Execution
id: 75df3b17-8bcc-4565-b89b-c9898acef911
status: experimental
description: Detects the execution of a AdFind for Active Directory enumeration
references:
- https://social.technet.microsoft.com/wiki/contents/articles/7535.adfind-command-examples.aspx
- https://github.com/center-for-threat-informed-defense/adversary_emulation_library/blob/master/fin6/Emulation_Plan/Phase1.md
- https://thedfirreport.com/2020/05/08/adfind-recon/
author: FPT.EagleEye Team, omkar72, oscd.community
date: 2020/09/26
modified: 2021/05/12
tags:
- attack.discovery
- attack.t1018
- attack.t1087.002
- attack.t1482
- attack.t1069.002
logsource:
product: windows
category: process_creation
detection:
selection:
CommandLine|contains:
- 'objectcategory'
- 'trustdmp'
- 'dcmodes'
- 'dclist'
- 'computers_pwdnotreqd'
Image|endswith: '\adfind.exe'
condition: selection
falsepositives:
- Administrative activity
level: medium
First, we have to understand and score this analytic’s event robustness. The data source
for this analytic is process_creation, so it could potentially trigger Windows Event
ID 4688 or Sysmon Event ID 1. This analytic references the Image field which does
not exist in Event ID 4688, but it does exist in Sysmon Event ID 1 3. 4688 has the
field NewProcessName, though it could be mapped to another field name in your SIEM
of choice. As a result, we assume the intent of this analytic is to identify command
line activity in Sysmon Event ID 1s.
Sysmon Event ID 1 is generated when Win32 API functions are called to create a new process 4. Therefore it is a user-mode data source and we place the observables in the U column.
Next, Image|endswith: '\adfind.exe' is placed at the Ephemeral level. An
adversary can easily obfuscate or change the Image value by renaming the file. The
command line arguments are placed at the Core to Adversary-Brought Tool level, since
the command line arguments are specific to the ADFind tool and require modifying source
code to evade. Since the CommandLine and Image observables in the analytic are
are combined with the boolean AND operator, the net robustness is the lower of the two, resulting in a Level 1 score for the overall
analytic. The entire analytic scores as a 1U.
Application (A) |
User-mode (U) |
Kernel-mode (K) |
|
|---|---|---|---|
Core to (Sub-) Technique (5) |
|||
Core to Part of (Sub-) Technique (4) |
|||
Core to Pre-Existing Tool (3) |
|||
Core to Adversary-brought Tool (2) |
EventID: 1
CommandLine|contains:
- ‘objectcategory’
- ‘trustdmp’
- ‘dcmodes’
- ‘dclist’
- ‘computers_pwdnotreqd’
|
||
Ephemeral |
Image|endswith: ‘\adfind.exe’ |
Important
An adversary can easily evade this analytic by renaming the executable. Can we engineer this analytic to make it more robust? Our options for increasing robustness are pivoting to a sensor that monitors kernel-level activity (moving to the right) or increasing the level our analytic operates at (moving up).
The robustness of this analytic can be increased by leveraging the OriginalFileName
field in Sysmon Event ID 1 instead of Image. It is trivial for an adversary to
change the Image name to avoid detection, but it is a bit more challenging for an
adversary to change the OriginalFileName, since that is derived from the
executable’s PE header. An adversary would need to recompile the tool or modify the
existing tool in a hex editor, both of which are more costly than simply renaming the
file. By instead detecting OriginalFileName|endswith: '\adfind.exe', this analytic moves
up a level to 2U.
Application (A) |
User-mode (U) |
Kernel-mode (K) |
|
|---|---|---|---|
Core to (Sub-) Technique (5) |
|||
Core to Part of (Sub-) Technique (4) |
|||
Core to Pre-Existing Tool (3) |
|||
Core to Adversary-brought Tool (2) |
EventID: 1
CommandLine|contains:
- ‘objectcategory’
- ‘trustdmp’
- ‘dcmodes’
- ‘dclist’
- ‘computers_pwdnotreqd’
OriginalFileName|endswith: ‘\adfind.exe’
|
||
Ephemeral |
Using the Summiting methodology, we have improved our analytic by just changing one field to identify adversary behavior and make it more difficult for them to evade detection of this analytic. This is the key goal of the project: to study how to engineer more robust analytics using threat-informed defense.
Assumptions and Caveats
While the process and goals described here could be extended to cover any attack surface, this Summiting 1.0 project has the following scope and limitations:
Focused on Windows systems. There is definitely room to create guidance for networks, cloud, virtual machines, and other platform types to improve analytics across various platforms. See: Future Work.
Engineered for robustness. While the efficacy of detection analytics are frequently described in terms such as precision and recall, this work emphasizes robustness. See Definitions.
Tampering is out of scope. Adversaries may evade detection by tampering with the data sources, but this project focuses on scenarios where the data source is trusted.
Tools and techniques change over time. The analytic score might change as well. This goes for updates of the OS, pre-existing tools, and new adversary tool functionality, not just at levels 4 and 5.
Higher scoring analytics are harder to build. This is due to the level of research required for defenders to map the higher level abstractions of TTPs behavior into the lower level of observables.
Other considerations. In addition to scoping out precision and recall, there are other important properties of analytics that are not considered here, such as the cost to engineer the analytic, the cost to collect the corresponding data, the cost to run the analytics at scale, etc. This is briefly touched on in Future Work.
We are always looking for feedback and public contributions! Open a GitHub issue to share your ideas, feedback, and scored analytics.
