Technique Investigation¶

This technique focuses on the repeated creation of compressed archive files, such as Zip files or WinRar files, in a short amount of time. While the creation of file archives may be a routine part of office work, it can also be indicative of staging files for exfiltration or can be paired with encryption to become the impact step of a ransomware attack. The behavior which identifies the distinction between benign usage and potential malicious usage is multiple archive events occurring in a short time frame. This indicates the use of a script or other automated process for creating archives, which is rare enough for normal user activity that it should minimize false positive detections.

Context Flowchart Walkthrough¶

This technique, which is indistinguishable from routine workflows except for volume, falls into the chained technique category of “Performing Abnormal Action.” The only differentiator we identified from legitimate usage was the volume and number of these actions in a short amount of time. This means that effective detection needs to rely on the chaining together of several individual events into a chain for proper detection.

Technique-Level Analysis¶

We researched a way in which we could pair the archive creation with exfiltration methods directly. However, we found that there is too much variation between specific exfiltration methods used in the attack chains that the resulting analytics would not have been very robust. Additionally, the environments in which we we tested these analytics had an accelerated timeline of known adversary activity because our “known bad” event logs came from adversary emulation exercises. Actual APT activity or ransomware campaigns may have compression and exfiltration occur out-of-order or on time-tables that we could not accurately predict.

The focus on the volume of archive creation is one behavior we identified that was most likely to filter out the routine usage and highlight potentially malicious behavior.

Original Analytic¶

powershell EventCode=4104 ScriptBlockText = "*Compress-Archive*"  ScriptBlockText = "*\\Temp\\*"
 | stats count min(_time) as firstTime max(_time) as lastTime by EventCode ScriptBlockText Computer UserID
 | rename Computer as dest
 | rename UserID as user
 | `security_content_ctime(firstTime)`
 | `security_content_ctime(lastTime)`
 | `windows_archive_collected_data_via_powershell_filter`

The original Splunk analytic we used for comparison focuses solely on the PowerShell usage of the “Compress-Archive” commandlet. Additionally, it only alerted on compression operations which occurred in a “Temp” directory. This analytic does filter out much of the benign usage with the inclusion of this directory filter. However, this is a brittle analytic. All an adversary need do to avoid triggering this is to compress files outside of folders named “Temp.” Also, this focus on PowerShell compression also leaves out scenarios where an adversary uses a standard archiving tool like WinZip or 7zip for their compression.

This analytic focuses only on Process Creation of a Pre-Existing Tool commonly used on the compression technique. The event code is generated from a Kernel level operation, so for the EventCode=4104 portion of the analytic scoring, we can place that in 3K.

However, the inclusion of the “Temp” directory as a way of filtering out noise is completely Ephemeral. If an adversary were to simply avoid working out of a folder titled “Temp,” the malicious behavior would be filtered out as benign.

Following the Boolean logic of how these components are being combined via “AND”, the overall analytic is thus scored as a 1K.

Improved Analytic¶

### CORRELATION
title: Multiple Archived Files
description: Detects multiple uses of archiving utilities indicative of staging activity
status: test
correlation:
   type: event_count
   rules:
      - archiving_utils
   group-by:
      - TargetObject
   timespan: 10m
   condition:
      gte: 5
---
### BASE RULE
title: Archiving Data Using Common Utilties
status: test
description: An adversary may compress data that is collected prior to exfiltration using 3rd party utilities
name: archiving_utils
author: MITRE
date: 2025-03-25
tags:
    - attack.collection
    - attack.t1560.001
logsource:
    product: windows
    category: process_creation
detection:
    selection:
        - OriginalFileName:
            - '7z.exe'
            - '7z*.exe'
            - 'winzip.exe'
            - 'winzip64.exe'
            - 'rar.exe'
        - CommandLine|contains:
            - 'Compress-Archive'
    condition: 1 of selection
falsepositives:
    - Legitimate user activity

The change in our analytic focused on substituting the Ephemeral string search of “Temp” with the timespan and count of Archiving Data Using Common Utilities. This elimination of the 1K analytic scoring immediately improved the analytic to a 3K, but it also introduced a far greater chance for false positives to be generated. To reduce this false positive opportunity, we focused on a number of events that would occur within a short timeframe. This eliminated the benign use case of a user who might be using archive tools on their workstation for approved business purposes. Scripting is the only common way to reach the volumes our analytic checks, and we find this to be an acceptable level of potential false positive alerts. Please note that the number of archive events and the time span may need to be adjusted for your organization.
